Heavy Wall ERW Steel Pipe High Pressure Steam Pipeline
Specification
Details | Content |
Product Name | Heavy Wall ERW Steel Pipe High Pressure Steam Pipeline |
Outer Diameter Range | 21.3mm - 660mm (1/2" to 26") |
Wall Thickness Range | 6.0mm - 22.2mm, maximum up to 30.96mm for custom heavy wall requirements |
Standard Length | 6m (20ft), 5.8m, 11.8m, 12m, SRL / DRL customized lengths available |
Nominal Pipe Size (NPS) | 2" / 3" / 4" / 6" / 8" and above, covering all common industrial pipeline sizes |
Schedule Options | SCH40, SCH80, SCH120, SCH160, custom heavy wall schedules for extra high pressure scenarios |
Material & Grade Options
Details | Content |
Carbon Steel Grades | Q235, Q345, S235JR, S355JR, 20# Steel, Grade A, Grade B |
Pipeline Special Grades | API 5L X42, X52, X60, X65, L250, L350 |
Alloy Steel Options | Low alloy grades for specified elevated temperature properties, meeting ISO 9330-2 standard |
Material Traceability | 100% mill test certificate provided, full raw material inspection before production |
Dimension & Weight Data (SCH40 / SCH80 Standard)
NPS | OD (mm) | SCH40 Wall Thickness (mm) | SCH40 Weight (kg/m) | SCH80 Wall Thickness (mm) | SCH80 Weight (kg/m) |
2" | 60.3 | 3.91 | 5.44 | 5.54 | 7.48 |
3" | 88.9 | 5.49 | 11.29 | 7.62 | 15.27 |
4" | 114.3 | 6.02 | 16.07 | 8.56 | 22.32 |
6" | 168.3 | 7.11 | 28.26 | 10.97 | 42.56 |
8" | 219.1 | 8.18 | 41.78 | 12.7 | 63.64 |
Manufacturing Process & Core Technology
Details | Content |
Welding Technology | High frequency electric resistance welding (ERW), no filler material added during welding, weld seam chemical composition 100% consistent with base metal |
Heating Principle | Adopts 50KHz-400KHz high frequency current skin effect and proximity effect, rapidly heats strip edges to melting point, then extruded by pressure rollers to form solid weld |
Post Weld Treatment | Full weld seam normalizing / annealing heat treatment, eliminates welding stress, improves toughness and pressure resistance performance |
Production Efficiency | Welding speed reaches 20-200 meters per minute, 25% lower production cost than seamless pipe of same specification, higher material utilization |
International Standards & Certifications
Details | Content |
Main Execution Standards | API 5L, ASTM A53, ASTM A106, GB/T 9711, ISO 9330-2, DIN EN 10219, DIN EN 10217 |
Certifications | CE marked, ISO 9001 quality system certified, support third party inspection by SGS, BV and other authoritative organizations |
Pressure Rating | Working pressure up to 16MPa, suitable for high pressure steam transmission scenarios up to 450℃ elevated temperature |
Dimensional Tolerance | Wall thickness tolerance ±0.2mm, outside diameter tolerance ±0.5%, strict size control for high pressure pipeline installation |
End Processing & Surface Treatment
Details | Content |
Pipe End Options | Plain end, beveled end (30°-35° for welding), threaded with coupling, chamfer, grooved, screw end |
End Protection | Plastic pipe cap, iron protector to avoid end damage during transportation |
Surface Treatment | Bare black finish, anti-rust oil coated, black varnish painted, galvanized, 3PE / FBE anti-corrosion coating for underground steam pipeline |
Custom Service | Support custom anti-corrosion requirements according to client's project environment |
Strict Quality Inspection Procedures
Details | Content |
Raw Material Inspection | Chemical composition analysis, mechanical property test for every batch of steel strip |
Online Weld Monitoring | Real time eddy current testing during welding process, automatic alarm for defective weld seam |
Full Body Hydraulic Test | 100% hydrostatic pressure testing according to standard, no leakage guaranteed |
Final Inspection | Ultrasonic examination for weld seam, dimensional check, visual appearance inspection before packaging |
Main Application
Details | Content |
Power Industry | High pressure steam pipeline for boiler system, power plant steam delivery main pipe |
Petrochemical Industry | High temperature fluid transmission, refinery process pipeline, chemical plant steam network |
District Heating System | Urban central heating high pressure steam pipeline, industrial park heat supply network |
Other Industrial Fields | Low and middle pressure fluid pipeline, steam transmission for pharmaceutical, fertilizer, shipbuilding industry |
Packaging & Delivery Terms
Details | Content |
Packaging Method | Bundle with steel strips, woven bag packaging, or custom packaging as client's requirement |
Loading Port | Tianjin Port, China, convenient for global sea transportation |
Delivery Time | Within 20-30 days after receiving deposit or L/C, according to order quantity |
Shipping Option | Container shipment, bulk carrier shipment for large volume order |
Payment & Cooperation Terms
Details | Content |
Accepted Payment Terms | T/T, Irrevocable L/C at sight, D/P, O/A for long term cooperative clients |
Supply Capacity | Monthly output over 15000 tons, support large scale engineering order delivery |
After Sales Service | 7*24 hours technical support, provide installation guidance, quality problem response within 12 hours |
Supporting Products | Provide matching pipe fittings including flange, tee, elbow, reducer for complete steam pipeline solution |
